• CAM & GROOVE •

Part A - Camlock (Cam & Groove)

Male Camlock to Female thread

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Thread: BSP and NPT

  • Maximum Operating Pressure: 150 PSI

  • Type: "A" Quick Disconnect

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part AA - Camlock (Cam & Groove)

Male Camlock to Male Camlock

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Maximum Operating Pressure: 150 PSI

  • Type: "AA" Quick Disconnect

  • Also known as " SPOOLS " or " Double Male "

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part B / BL - Camlock (Cam & Groove)

Female Camlock ( Locking / Non-Locking ) to Male thread

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Maximum Operating Pressure: 150 PSI

  • Type: "B" or "BL ( Locking )" Quick Disconnect

  • All Couplers Supplied with Buna-N Gaskets

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part C / CL - Camlock (Cam & Groove)

Female Camlock ( Locking / Non-Locking ) to Hose Shank

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Maximum Operating Pressure: 150 PSI

  • Type: "C" or "CL ( Locking )" Quick Disconnect

  • All Couplers Supplied with Buna-N Gaskets

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part D / DL - Camlock (Cam & Groove)

Female Camlock ( Locking / Non-Locking ) to Female Thread

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Maximum Operating Pressure: 150 PSI

  • Type: "D" or "DL ( Locking )" Quick Disconnect

  • All Couplers Supplied with Buna-N Gaskets

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part DD / DDL - Camlock (Cam & Groove)

Female Camlock to Female Camlock Both Ends ( Locking/Non )

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Maximum Operating Pressure: 150 PSI

  • Type: "DD" or "DDL ( Locking )" Quick Disconnect

  • All Couplers Supplied with Buna-N Gaskets

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part E - Camlock (Cam & Groove)

Male Camlock to Hose Shank

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Maximum Operating Pressure: 150 PSI

  • Type: "E" Quick Disconnect

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part F - Camlock (Cam & Groove)

Male Camlock to Male Thread

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Thread: BSP and NPT

  • Maximum Operating Pressure: 150 PSI

  • Type: "E" Quick Disconnect

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part DC - Camlock (Cam & Groove)

Dust Cap Camlock

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Dust Caps for Male Camlock Ends

  • Type: "DC" Quick Disconnect

  • All Couplers Supplied with Buna-N Gaskets

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials

Part DP - Camlock (Cam & Groove)

Dust Plug Camlock

  • Body Material: Aluminum, Brass, Nyglass, Polypropylene,

                              304 and 316 Stainless Steel

  • Size: 1/2" to 12" *

  • Dust Plugs for Female Camlock Ends

  • Type: "DP" Quick Disconnect

For Special orders contact us: Information

* Some sizes may not be avaliable in certain materials
